Automatic spraying machine suitable for small batches of irregular wood products
Say Goodbye to the Hassle of Repeatedly Setting Spray Paths for Irregular, Small-Batch Products
Spraying irregular, small-batch wooden products, such as cabinets of varying sizes or dining tables of different shapes, is an extremely challenging task:
* Differences in shape necessitate repeated spray path settings
* Paint waste and rework
* High reliance on skilled spray painters
* Inconsistent paint thickness due to over- or under-application
This 5-axis sprayer provides precise, automated coating for wood products of varying shapes and sizes, improving efficiency, consistency, and production scalability.
Achieve Consistent Quality and Scale Your Production with Imluchy’s Turnkey Finishing Systems.
Our Solution: 5-Axis Automated Spray Painting Machine with 3D Scanning and Automatic Flipping Function
This advanced automated spray painting machine aims to:
* Laser scanning and 3D recognition of three-dimensional objects, automatically planning the spraying path
* PLC control ensures consistent product results
* The machine can independently complete spraying and flipping, reducing manual intervention
* 24/7/365 non-stop spraying, improving efficiency.
Why Choose 5-axis machine？
1. PLC computer control ensures highly consistent product coating results, reducing paint and time wasted on rework.
2. 3D scanning and automatic product flipping make it easier for innovative technology factories to build trust and establish deeper partnerships with customers.
3. Machinery and automation are the future trend; early adoption of automation allows for faster integration with the world and the establishment of a strong corporate image.
Standard machines or customized spray coating production lines can be selected according to different requirements:
5-axis automatic spray coating machine (QH-5X-3D)
- Suitable for products of different shapes and sizes with complex surfaces
- Small batches, multiple products
- Using water-based paints
Customized automatic spray coating line (QH-LINE-CU)
- Suitable for regular products such as flat and plated surfaces
- Multiple batches, single products
- Requires IR and UV leveling and drying
Technical Highlights
* Full Servo Computer Control: Suitable for spraying products of various shapes and sizes, reducing processing steps.
* Independent Spray Gun Control: Each spray gun, paint, and air path is independently controlled by a computer, allowing for flexible switching and efficient spray gun arrangement.
* Touchscreen Industrial Computer and 3D Scanning: Automated production processes require no manual editing, are easy to learn, and offer more accurate measurements.
* Electric Turntable: Motor-driven worktable with frequency converter speed regulation ensures smoother rotation.
Manual Spraying vs Automatic Coating Machine
|
|
Manual Spraying |
|
|
Feature |
Manual | Automatic |
|
Consistency |
Low: Inconsistent finished product results due to variations in worker skill and condition | PLC control ensures consistent results within the same batch |
|
Efficiency |
Medium: Manual spraying leads to fatigue | High: Machines can operate 24/7 |
|
Labor Cost |
High: Skilled painters are scarce and their wages are significantly higher than machine costs | Low: Automated production allows for cost recovery in as little as three months |
|
Paint Costs |
High: Easily affected by worker skill level | Low: Computer-planned optimal paths, can be combined with a paint recycling system, saving up to 50% on paint |
Ready to Automate Your Coating Process?
Get a Free Layout Design & Cost Analysis.
Don't let finishing be your bottleneck. Contact our engineers today for a customized solution.
FAQ
Tell us about your project requirements and we will figure out a solution that will meet your budget and design expectations.
