6 Axis Spray Painting Machine for Irregular Plastic Parts & Audio Cases | High Precision Automated Coating System

Common Challenges of Spraying Multiple Colors in Small Batches

• Frequent color changes lead to waste of paint and cleaning solvents.

• Incomplete cleaning results in paint mixing, wasting paint and producing poor-quality finished products.

• Frequent paint color changes significantly reduce the usage frequency of core precision components such as paint valves.

Traditional single-gun, single-pump systems struggle to efficiently handle multi-colored workpieces.

Solution: Dual-Pump Rapid Color Change System

The machine uses a dual-pump, multi-gun combination, with each pump using one or several similar colors:

• Fundamentally eliminates the possibility of color mixing

• Reduces color change time from tens of minutes to just a few minutes

• Significantly reduces the cost of paint and paint cleaning solvents

• Simplifies the commissioning process and increases the lifespan of core components such as the color change valve

Key Advantages

• Physical isolation of different colors fundamentally eliminates color mixing: Even high-contrast colors like black and white will not mix.
• Significantly reduced cleaning efficiency and material waste: Statistics show that each thorough cleaning of the oil pump and spray gun consumes 54 kg of cleaning solvent and 5 kg of paint.
• Simplified process: Non-stop spraying reduces the need for frequent adjustments to the spray path.

Applications：

The dual-pump, multi-gun automatic paint change system is suitable for any application requiring frequent paint color changes:

• Audio enclosures and speaker housings

• Irregularly shaped plastic parts (ABS, PC, PP)

• Cosmetic packaging (plastic bottle caps, glass bottles)

• Automotive interior components

• Consumer electronics housings

Technical Highlights

Working Pump (Pump A): Operates continuously, ensuring uninterrupted spraying.

Standby Pump (Pump B): Simultaneously, Pump B automatically performs the following background operations:

• Evacuation: Drains residual old paint back to the original container or waste container.
• Cleaning: Introduces solvent to thoroughly clean Pump B and its connected piping.
• Preparation: After cleaning, draws paint from the new color container, completing the filling process and entering standby mode.

Instant Switching: When yellow needs to be sprayed, the system instantly closes the outlet valve of Pump A and simultaneously opens the outlet valve of Pump B.

Role Reversal: After the switch is complete, Pump A immediately enters the cleaning and preparation process for the next color, preparing for the next switchover.
